7.1 Standard Accessory Mounting Adapter Assembly—P2002B
Chapter 7: Accessories
3. Tilt the accessory (C) that you are installing 10° toward the Integris®
Headwall System accessory rail (D).
4. Install the accessory (C) onto the accessory rail (D).
5. Tilt the accessory (C) downward, and ensure the mounting adapter
assembly (B) is seated properly onto the accessory rail (D).
6. Switch the white latch (A) from the right position to the left position and
lock the mounting adapter assembly (B) in place on the accessory rail (D).
WARNING:
Ensure the accessory is installed properly onto the Integris® Headwall
System. Failure to do so could result in personal injury or equipment
damage.
7. Give the accessory (C) a small tug outward to ensure that th
e mounting
adapter assembly (B) is properly installed onto the accessory rail (D).
Removal
To remove the mounting adapter assembly (B) from the headwall accessory
rail, reverse the installation procedure.
7
Integris® 2001 Headwall System Service Manual (man148ra) Page 7 - 7
