7.3 Mercurial and Aneroid Sphygmomanometer Mount—P102402/P102502 (P2001)
Chapter 7: Accessories
7.3 Mercurial and Aneroid Sphygmomanometer Mount—
P102402/P102502 (P2001)
The sphygmomanometer mount may be installed at any point on the upper
accessory track of the console raceway.
Installation
Tools required: None
1. Pull the latch (A) to open it, and set the sphygmomanometer mount (B) on
the upper accessory track (C) (see figure 7-3 on page 7-10).
Figure 7-3. Mercurial and Aneroid Sphygmomanometer Mount P102402/P102502
B
B
A
A
C
m148_052
2. Push in on the latch (A) to tighten the mount (B) on the track (C).
3. Give the sphygmomanometer mount (B) a small tug to ensure it is securely
installed.
Page 7 - 10 Integris® 2001 Headwall System Service Manual (man148ra)
