7.7 Utility Bottle Slide Mounting (P2001)
Chapter 7: Accessories
7.7 Utility Bottle Slide Mounting (P2001)
Tools required: None.
Installation
1. Install the utility bottle slide mounting (A) on the upper accessory rail (B)
(see figure 7-7 on page 7-15).
Figure 7-7. Utility Bottle Slide Mounting
B
C
A
m148a056
NOTE:
The utility bottle slide mounting may also be installed on the lower accessory
rail (C).
2. Make sure that the top hook (D) is securely seated on the accessory rail (B)
by giving it a small tug.
7
Integris® 2001 Headwall System Service Manual (man148ra) Page 7 - 15
