Voltage Distribution
Chapter 3: Theory of Operation
Voltage Distribution
Integris® 2001 Headwall System with Raceway
Figure 3-1. AC Voltage Distribution to the Raceway
Communications
m148_006
Standard power
Emergency power
Raceway ground terminals
}
Reference ground
Ground bar
Gas piping area
6 AWG reference ground wire
