4.5 Ground Jack Receptacle
Chapter 4: Removal, Replacement, and Adjustment Procedures
Replacement
1. Connect the ground wire to the receptacle terminal, and tighten the fastener
(E).
2. Align the receptacle ground plate with the device plate.
3. Install and tighten the screws (D).
4. Install the faceplate (B) with screws (C) on the raceway.
5. Test for availability of ground with a digital multimeter.
Page 4 - 12 Integris® 2001 Headwall System Service Manual (man148ra)
