4.4 Line Voltage Switch
Chapter 4: Removal, Replacement, and Adjustment Procedures
4. Take out the switch raceway retaining screws (D), and remove the switch
(A).
5. Record the positions of the color-coded wires on the switch terminals.
6. Using the screwdriver, loosen the terminal screws on the switch, and
remove the wires from the switch (A).
Replacement
1. Place the color-coded wires in their original positions on the switch (A).
2. Tighten the terminal screws to hold the wires firmly in place.
3. Install the switch (A) on the raceway.
4. Install and tighten the retaining screws (D).
5. Place the faceplate (B) on the raceway.
6. Install and tighten the retaining screws (C).
7. Remove the lock out and out-of-service tags.
8. Set the circuit breaker to the ON position.
9. Test the switch (A) to ensure it is operational.
Page 4 - 10 Integris® 2001 Headwall System Service Manual (man148ra)
