WittRock Integris 2001 - Regulations, Standards, and Codes

Specifications
Chapter 1: Introduction
Table 1-7. Receptacle Specifications
1
Description Specification
Hospital-grade receptacle NEMA 5-15R or 5-20R
Hospital-grade is indicated
by a green dot on the face of
the receptacle.
Single phase 2 wires plus ground
Voltage 125V AC
Amperage 15 or 20 amp
Receptacle color Ivory = standard power
duplex
Red = emergency power
(critical branch)
Black = locking single
Orange = isolated ground
Regulations, Standards, and Codes
USA
Sections and Units
Category guide designation = QQXX.
Isolated Power Wall Modules
Category guide designation = KEXS.
Canada (CUL)
Sections and Units
Category guide designation = QQXX7.
Isolated Power Wall Modules
Category guide designation = KEXS7.
Integris® 2001 Headwall System Service Manual (man148ra) Page 1 - 11
