4.2 Single Receptacle
Chapter 4: Removal, Replacement, and Adjustment Procedures
4.2 Single Receptacle
Tools required: Screwdriver Phillips head screwdriver
Removal
SHOCK HAZARD:
Locate the involved building circuit breaker panel. Set the involved
circuit breaker to OFF. Lock out and tag out the breaker. Failure to
follow this procedure could result in personal injury or equipment
damage.
1. Set the involved circuit breaker to OFF.
2. Lock out and tag the circuit breaker.
3. Using the phillips head screwdriver, remove the screws (B) and the
faceplate (C) from the single receptacle device plate (see figure 4-2 on
page 4-5).
Figure 4-2. Single Receptacle Removal
4
m148a013
Integris® 2001 Headwall System Service Manual (man148ra) Page 4 - 5
