TechnicalparameterstoEURegulationNo.813/2013
40 TechnicalparameterstoEURegulationNo.813/2013
Type BWL-
1S(B)-05/230V
BWL-
1S(B)-07/230V
BWL-
1S(B)-10/400V
BWL-
1S(B)-14/400V
BWL-
1S(B)-16/400V
Air/water heat pump (Yes/No) Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Water/water heat pump (Yes/No) No No No No No No No No No No
Brine/water heat pump (Yes/No) No No No No No No No No No No
Low temperature heat pump (Yes/No) No Yes No Yes No Yes No Yes No Yes
With booster heater (Yes/No) Yes/No Yes/No Yes/No Yes/No Yes/No Yes/No Yes/No Yes/No Yes/No Yes/No
Combi boiler with heat pump (Yes/No) No No No No No No No No No No
Values for mediumtemp.(55°C)/lowtemp.(35°C) application with average climate conditions
Information Symbol Unit 55°C 35°C 55°C 35°C 55°C 35°C 55°C 35°C 55°C 35°C
Rated heating output (*) P
rated
kW 5 6 6 7 11 10 13 12 15 12
Specified output for partial load at
20 °C room air temperature and
outdoor air temperature
Tj = -7 °C Pdh kW 4.7 5.2 6.0 5.9 8.3 8.5 9.2 11.0 10.1 10.7
Tj = +2 °C Pdh kW 2.9 3.1 3.5 3.7 5.2 5.5 7.3 6.7 8.3 7.0
Tj = +7 °C Pdh kW 2.2 2.3 2.9 2.8 4.5 5.0 4.7 5.1 4.9 5.2
Tj = +12 °C Pdh kW 2.6 2.9 3.1 3.4 5.1 5.9 4.9 5.1 6.0 6.2
Tj = dual mode temperature Pdh kW 4.7 5.2 4.7 5.9 8.0 9.3 8.9 10.8 10.7 10.6
Tj = operating temperature limit Pdh kW 4.6 5.0 5.5 6.6 8.2 9.3 9.4 10.8 10.1 10.6
For air/water heat pump Tj =
-15 °C (where TOL < -20 °C)
Pdh kW - - - - - - - - - -
Dual mode temperature T
biv
°C -3 -7 -3 -7 -3 -8 -3 -8 -3 -7
Seasonal central heating
efficiency
n
s
% 115 168 133 180 130 195 131 178 125 172
Specified coefficient of
performance or primary energy
ratio for partial load at 20 °C
room temperature and outdoor
air temperature
Tj = -7 °C COPd - 2.04 2.91 2.11 2.96 2.05 2.97 2.03 2.86 1.9 2.59
Tj = +2 °C COPd - 2.81 4.06 3.41 4.33 3.22 5.00 3.25 4.04 3.14 4.27
Tj = +7 °C COPd - 3.60 5.77 4.12 5.95 4.30 6.21 4.77 6.68 4.73 5.91
Tj = +12 °C COPd - 5.59 8.06 5.31 7.21 5.30 7.36 5.20 8.58 6.18 7.77
Tj = dual mode temperature COPd - 2.04 2.91 2.60 2.96 2.51 3.08 2.51 2.86 2.27 2.59
Tj = operating temperature limit COPd - 1.88 2.71 1.85 2.66 1.86 2.81 1.86 2.86 1.79 2.41
For air/water heat pump Tj =
-15 °C (where TOL < -20 °C)
COPd - - - - - - - - - - -
For air/water heat pump:
Operating temperature limit
TOL °C -10 -10 -10 -10 -10 -10 -10 -10 -10 -10
Heating water operating
temperature limit
WTOL °C 55 55 55 55 55 55 55 55 55 55
Power consumption in operating
modes other than the operating
condition: OFF state
P
OFF
kW 0.006 0.006 0.007 0.007 0.026 0.026 0.026 0.026 0.017 0.017
Power consumption in operating
modes other than the operating
condition: Thermostat OFF state
P
TO
kW 0.012 0.008 0.011 0.011 0.026 0.026 0.026 0.026 0.19 0.019
Power consumption in operating
modes other than the operating
condition: Standby mode
P
SB
kW 0.021 0.021 0.010 0.010 0.026 0.026 0.026 0.026 0.026 0.026
Power consumption in operating
modes other than the operating
condition: Crankcase heater mode
P
CK
kW 0.000 0.000 0.000 0.000 0.000 0.000 0.000 0.000 0.000 0.000
Booster heater rated heating
output
P
sup
kW 0.7 / 0 0.9 / 0 0.9 / 0.0 0.1 / 0.0 2.6 / 0.0 0.8 / 0.0 3.5 / 0.0 2.8 / 0.0 4.9 / 0 1.3 / 0
Energy supply type - - electrical electrical electrical electrical electrical
Output control fixed/variable variable variable variable variable variable
Indoor sound power level L
WA
dB 27 27 42 42 42 42 44 44 44 44
Outdoor sound power level L
WA
dB 59 59 61 61 61 61 63 63 64 64
For air/water heat pump:
Nominal air flow rate, outdoors
- m3/h 2600 2600 2600 2600 3500 3500 4200 4200 4200 4200
For water/brine-water heat pump:
Nominal water or brine flow rate
- m3/h - - - - - - - - - -
