Wolf BWL-1S-07 - Siting the Indoor Module; Minimum Clearances for the Indoor Module; Securing the Appliance with the Suspension Bracket

3064298_201805 21
Sitingtheindoormodule
10 Sitingtheindoormodule
10.1 Minimumclearancesfortheindoormodule
≥800
≥40
≥40
≥1000
≥150
Fig.:Frontviewofindoormodule
Fig.:Planviewofindoormodule
10.2 Securingtheappliancewiththesuspensionbracket
Wheninstallingtheappliance,ensurethatthexingshavesufcientloadbearingcapacity.Inaddition,
take into account the condition of the wall, otherwise refrigerant and water could escape, resulting in a
riskofooding.
1. MarktheØ12holestobedrilledforthesuspensionbracket,takingintoaccounttheminimumclearances.
2. Insert the rawl plugs and fit the suspension bracket using the screws supplied.
3. Hang the indoor module into the suspension bracket using the mounting stay.
344
Fig.:RearviewofindoormoduleFig.:Suspensionbracket
≥245
Ceiling
Mounting stay
