Wolf BWL-1S-07 - 35 Specification

3064298_201805 99
Specication
35 Specication
TYPE BWL-1S(B)-05/230V BWL-1S(B)-07/230V
Width x height x depth of outdoor unit
(incl. feet and front doors)
mm 964 x 862 x 363
Width x height x depth of indoor unit
(incl. feet and front doors)
mm 440 x 790 x 340
Weight of outdoor/indoor unit kg 66 / 33
Refrigerantcircuit
Refrigerant type / GWP - R410A / 2088
Charge weight / CO
2
equiv. kg / t 2.15 / 4.49
Max. length of refrigerant line m 25
Quantityofrefrigeranttobeadded,
line length > 12 m - 25 m
g/m 60
Refrigerant oil / charge weight - -/ ml FVC68D FV68S / 650
Compressor type Rotating piston
Maximum operating pressure bar 43
Heatingoutput/COPtoEN14511
A2/W35 rated output kW / - 3.4 / 3.7 5.0 / 3.5
A7/W35 rated output kW / - 5.2 / 4.9 7.3 / 4.8
A-7/W35 max. output kW / - 5.1 / 2.9 6.2 / 2.7
Output range at A2/W35 kW 1.9 - 6.6 1.9 - 8.8
Coolingcapacity/EERtoEN14511
A35/W7 rated output kW / - 4.5 / 2.5 7.6 / 2.7
A35/W18 rated output kW / - 6.1 / 3.5 9.0 / 3.8
Compressor output range at A35/W18 kW 1.6 - 6.9 2.9 - 9.6
Sound,outdoorunit
Sound power level (based on EN 12102/EN ISO 9614-2)
for A7/W55 at rated heating output
dB(A) 59 61
Max. sound power level dB(A) 61 63
Max. sound power level in reduced night mode dB(A) 56 56
Applicationlimits
Operating limit temperatures, heating mode °C +20 to +55
Operating limit temperatures, cooling mode °C +7 to +20
Max. heating water temp. with electric heater °C 75
Min./max. operating limit temps, air in heating mode °C -20 / +35
Min./max. operating limit temps, air in cooling mode °C +10 / +45
Heatingwater
Minimumowrate l/min 15 15
Nominalwaterowrate l/min 16 19.7
Maximumwaterowrate l/min 24.7 24.7
Heat pump pressure drop at nominal mbar 54 78
Residualheadatnominalwaterowrate mbar 540 490
Maximum operating pressure bar 3
Heatsource
Airowrateatnominaloperatingpoint m³/h 2600
Connections
HTGow/return//DHWowconnection mm 28x1
Connection, refrigerant lines UNF 5/8 + 7/8
Dimensions, refrigerant lines mm 10x1 + 16x1
Dimensions, condensate line, outdoor unit mm 16
Electrics,outdoorunit
Power supply / fuse protection, outdoor unit 1~NPE, 230 V AC, 50 Hz / 20 A(C)
Max. fan power consumption W 57
Standby power consumption W 9
Output/current/cosφatA7/W35 kW/A/- 1.3 / 5.8 / 0.97 1.52 / 6.8 / 0.97
Maxpowerconsumption/compressorcurrent/cosφ
within application limits
kW/A/- 3.6 / 16 / 0.92
Compressor starting current A 10
Compressor starting current with blocked rotor A 25
Starting current (charging of DC capacitors) A 35
IP rating, outdoor unit IP 24
Maximum no. of compressor starts per hour 1/h 6
Pulse number p 2
Compressor frequency range Hz 20 - 70 20 - 90
Electrics,indoorunit
Power supply / fuse protection, heating element
1)
Either 3~NPE, 400 V AC, 50 Hz / 16 A(B) or
1~NPE, 230 V AC, 50 Hz / 32 A(B)
Power supply / fuse protection, control voltage 1~NPE, 230 V AC, 50 Hz / 16 A(B)
Power consumption, electric heater
1)
kW 2 / 4 / 6 or 3 / 6 / 9
Power consumption, pump W 3 - 45
Standby power consumption W 5
Maximum power consumption, 6 kW electric heater
1)
A 8.7 (400 V AC) / 26.1 (230 V AC)
Maximum power consumption, 9 kW electric heater
1)
A 13 (400 V AC)
IP rating, indoor unit IP 20
1)
Available as an accessory for the BWL-1SB
