Contractorparameters
28.2 Contractorparametersdescription
Contractor
parameter
Description
WP001 Forsettingapre-conguredsystemversionsubjecttoheatpumpdesignandapplication
(see"Overviewofsystemcongurations").
WP002 For optionally assigning one of the following functions to programmable input E1:
Setting Function input E1
None No function
RT Heating block (room thermostat)
Contact open - blocked
Contact closed - heating mode enabled
DHW DHW block
Contact open - blocked
Contact closed - DHW mode enabled
RT/DHW Heating and DHW block
Contact open - blocked
Contact closed - heating mode and DHW mode enabled
Zirkomat Zirkomat (DHW circulation remote control)
WheninputE1isconguredto"Zirkomat",outputA1isautomaticallysetto
"Zirkomat" and blocked for further settings. When input E1 is closed, output
A1 is activated for 5 minutes. When input E1 has switched OFF and 30 minutes
have elapsed, the remote control function is re-enabled for the next operation.
DPM/MaxTh Dew point monitor/maximum thermostat contact open –
Cooling mode/heating mode/DHW mode blocked
Contact closed -
Cooling mode/heating mode/DHW mode enabled
WP003 For optionally assigning one of the following functions to programmable output A1:
Setting Function output A1
None No function
Zirk20 DHW circulation pump activation 20 % (2 mins ON, 8 mins OFF)
Zirk50 DHW circulation pump activation 50 % (5 mins ON, 5 mins OFF)
Zirk100 DHW circulation pump activation 100 % (continuous operation)
Alarm Alarm output
Is set if a fault is present.
Zirkomat Zirkomat (DHW circulation pump)
Output A1 is activated for 5 minutes when input E1 closes. If output A1 is
conguredto"Zirkomat",inputE1isautomaticallysetto"Zirkomat"and
blocked for further settings. When input E1 has switched OFF and 30 minutes
have elapsed, the remote control function is re-enabled for the next operation.
Defrost ODU in defrost mode
Is set if the heat pump is defrosting.
E.g.forusewiththe51/52(BMS)conguration
Add HG Additional heat generator
Is set if a demand is issued to the additional heat generator.
(Onlypossiblewithcongurations33and34.)
Note:
Theelectricheaterisdeactivatedforcongurations33and34aslongasthe
compressor and additional heat generator are operational.
Compressor ON Is set if the compressor is active.
