Wolf BWL-1S-07 - System Configuration 52

3064298_201805 83
Systemcongurations
29.2.12 Systemconguration52
BWL-1S(B)
●Splitair/waterheatpump
● ON/OFF activation(atinputE2/SAF)
Externaldemand/controlby
buildingmanagementsystem(BMS)
ExternaloatingcontactatinputE2/SAF:
 Open → heatpumpOFF
 Closed → compressorON
Notes:
-
Application limits: Compressor T_FL/T_RTN = 55 °C, elec. heater T_FL = 75 °C
- The electric heater is not activated (except for frost protection and defrosting)
- CongureoutputA1todefrost(WP003=Defrost)
 →Indefrostmode,outputA1isswitched
in order to display defrost mode to the BMS.
- Ensure max. compressor starts per hour by BMS
- Ensuremax.owtemperaturebyBMS
ON - OFF
SF
A 3-way diverter valve for
central heating/DHW and
a feed/heating circuit pump
are integrated into the
indoor module
Indoor moduleOutdoor module
DHWheatingmodeforsystem
conguration52
Inthissystemconguration,theappliancecancarryoutDHWheat-upautomatically
on demand. DHW heat-up mode has priority over BMS mode.
DHWheat-upmodecanbesuppressedinsystemconguration52byremoving
the SF cylinder sensor, carrying out a parameter reset and resetting the system
conguration.
In this case, disconnect integral 3-way diverter valve for HTG/DHW.
Important information:
In these schematic diagrams, shut-off valves, air vent valves and safety equipment are not fully represented.
These should be provided for each system individually, in line with the applicable standards and regulations.
Hydraulic and electrical data can be found in the "Hydraulic System Solutions" technical guide.
