Woodward GCP-30 Series Configuration

Manual 37278B GCP-30 Series - Genset Control
© Woodward Page 153/174
MUX
No.
Contents (words)
Unit Note
18/1 55
Internal alarm 3 Bit 15 = 1 \
Bit 14 = 1 /
F3: Time-overcurrent, level 2 or
inverse time-overcurrent, IEC255
Note – On double /fourfold bits the follow-
ing is valid: If the indicated bit combination
is fulfilled (
high byte and low byte) ,the
message is active (otherwise inactive).
Bit 13 = 1 \
Bit 12 = 1 /
F3: Generator overspeed (Pickup)
Bit 11 = 1 \
Bit 10 = 1 /
Import power 0 kW not reached
Bit 9 = 1 \
Bit 8 = 1 /
F3: Generator unbalanced load
Bit 7 = 1 \
Bit 6 = 1 /
F3: Time-overcurrent, level 1
Bit 5 = 1 \
Bit 4 = 1 /
Interface fault Y1-Y5
Bit 3 = 1 \
Bit 2 = 1 /
F1: Maintenance call
Bit 1 = 1 \
Bit 0 = 1 /
Start failure
18/2 56
Internal alarm 4 Bit 15 = 1 \
Bit 14 = 1 /
F1: Analog input [T1], level 1
Note – On double /fourfold bits the follow-
ing is valid: If the indicated bit combination
is fulfilled (
high byte and low byte) ,the
message is active (otherwise inactive).
Bit 13 = 1 \
Bit 12 = 1 /
F3: Analog input [T1], level 2
Bit 11 = 1 \
Bit 10 = 1 /
F1: Analog input [T2], level 1
Bit 9 = 1 \
Bit 8 = 1 /
F3: Analog input [T2], level 2
Bit 7 = 1 \
Bit 6 = 1 /
F1: Analog input [T3], level 1
Bit 5 = 1 \
Bit 4 = 1 /
F3: Analog input [T3], level 2
Bit 3 = 1 \
Bit 2 = 1 /
F1: Analog input [T4], level 1
Bit 1 = 1 \
Bit 0 = 1 /
F3: Analog input [T4], level 2
18/3 57
Internal alarm 5 Bit 15 = 1 \
Bit 14 = 1 /
F1: Analog input [T5], level 1
Note – On double /fourfold bits the follow-
ing is valid: If the indicated bit combination
is fulfilled (
high byte and low byte) ,the
message is active (otherwise inactive).
Bit 13 = 1 \
Bit 12 = 1 /
F3: Analog input [T5], level 2
Bit 11 = 1 \
Bit 10 = 1 /
F1: Analog input [T6], level 1
Bit 9 = 1 \
Bit 8 = 1 /
F3: Analog input [T6], level 2
Bit 7 = 1 \
Bit 6 = 1 /
F1: Analog input [T7], level 1
Bit 5 = 1 \
Bit 4 = 1 /
F3: Analog input [T7], level 2
Bit 3 = 1 \
Bit 2 = 1 /
--Internal--
Bit 1 = 1 \
Bit 0 = 1 /
--Internal--
