Xerox Phaser 6600 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-21
ASIC Test
ASIC Test reads the device ID of the REMORA-EX via ZoranQuatro4530 and performs the Zoran
Quatro4530 and REMORA-EX tests.
Engine Test
IOT Test provides the communication test between the IOT. In this communication test, the IOT
status register is read for checking whether the commands are exchanged normally.
Hard Drive Test
Use the Device Diagnostic Command to perform the Hard Disk Test.
USB Host Test
USB Host Test checks the communication between a USB Host port and the USB devices connected to
the USB Host port.
* This test menu is for obtaining the USB authentication. To use this test, you will need the devices
approved by the certification authority.
Normal Error
CHECK OK ASIC CHECK NG
Normal Error
CHECK OK IOT ERROR
Normal Error
CHECK OK Hard Disk ERROR

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
