Xerox Phaser 6600 Service Manual

Image Quality
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
3-3
Image Quality Troubleshooting Chart
When an image quality problem occurs during printing, output a sample print to determine and grasp
the nature of the problem, then use the list of problem descriptions on page 3-4 to select a
troubleshooting procedure from the Image Quality FIP.
If the problem persists even after the troubleshooting with the Image Quality FIP, check using the
Image Quality FIP again, and then replace the "Possible causative parts" listed in the Image Quality
FIP one by one, and also troubleshoot using the procedures in Chapter 2, Error Troubleshooting.
Start
No
Yes
Test Prin t ing
Carry out the corresponding troubleshooting.
End
The trouble is restored?
Is there a corresponding FIP?
No
Yes
Remove Toner Cartridge, shake it several
times, and reinstall it.
End
The trouble is restored?
Yes
No
Replace Toner Cartridge, Imaging
Unit, Transfer Belt, and Fuser
Assembly one by one.
