General Information
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
1-40
Xerographics & Transfer
s6600-260
Imaging Unit Y
Transfer Belt Assembly
1st BTR Roller (Y) 1st BTR Roller (M)
1st BTR Roller (C)
1st BTR Roller (K)
Intermediate Transfer Belt
Back Up Roller
Belt Cleaner
Imaging Unit M
Imaging Unit C
Imaging Unit K
CTD Sensor Assembly
Drum
BCR
Cleaning Roller
Cleaning Blade
Magnet Roller
Auger
Auger
Auger
Trimmer Rod
CTD Sensor
Transfer Roller Assembly
Transfer Roller 2
Eliminator

Table of Contents

Other manuals for Xerox Phaser 6600

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Xerox Phaser 6600 and is the answer not in the manual?

Xerox Phaser 6600 Specifications

General IconGeneral
ColorYes
Duplex printingNo
Print technologyLaser
Maximum resolution600 x 600 DPI
Time to first page (black, normal)9 s
Time to first page (color, normal)10 s
Print speed (black, normal quality, A4/US Letter)36 ppm
Maximum duty cycle80000 pages per month
Number of print cartridges-
Internal memory256 MB
Processor frequency533 MHz
Maximum internal memory768 MB
Sound pressure level (printing)53 dB
Total input capacity700 sheets
Total output capacity250 sheets
Paper tray media typesCard stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)A4
Standard interfacesUSB 2.0
USB 2.0 ports quantity1
AC input frequency50 - 60 Hz
Power consumption (standby)65 W
Power consumption (printing)535 W
Sustainability certificatesENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Weight25500 g
Dimensions (WxDxH)429.26 x 487.68 x 383.54 mm
