Xerox Phaser 6600 Service Manual

Service Parts Disassembly
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
4-115
Covers
SFP Top Cover Assembly
PL19.1.1
WARNING: The Fuser is very hot. Take added care when handling the fuser to avoid being burned.
1. Remove the Right Cover Assembly. (page 4-131)
2. Remove the Left Cover Assembly. (page 4-134)
3. Remove the Left Sub-top Cover. (page 4-126)
4. Remove the Exit Cover. (page 4-125)
5. Open the Top Cover Assembly.
6. Remove the Transfer 2 Link (PL19.1.4) from the Transfer Link Coupling.
7. Remove the two screws (silver, tapping, 8mm) that attach the Right Hinge Bracket (PL19.1.20) to
the printer and remove the bracket.
8. Shift the Top Cover Assembly to the right to release the cover from the Left Hinge Bracket
(PL19.1.15), then lift up to remove the cover from the printer.

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
