Xerox Phaser 6600 Service Manual

Wiring
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
7-28
WorkCentre 6605 General Wiring Diagram
MCU Board
PL18.1.13
1
2
3
5
6
13
Harness Switch Assembly
PL18.1.31
Main Switch
Fusing Assembly
PL7.1.1
Drive Assembly
PL3.1.1
Main Motor
Sub Motor
Development Motor
Laser Assembly
PL7.1.1
IP Board
PL18.1.22
Fax Board
PL18.1.41
Scanner
Assembly
PL51.1.1
USB HUB Board
PL19.1.15
MFP Console
Assembly
PL1.1.1
Speaker
LVPS
PL18.1.34
Main Fan
PL4.1.13
Rear Interlock Switch
PL14.1.13
Door Interlock Switch
PL19.1.30
Sensor Toner Full
PL4.1.17
P/J29 P/J203 P/J5071 P/J507
P/J42
P/J41
P/J503
P/J501
P/J40
P/J48
P/J47
P/J508
P/J509
P/J43P/J431P/J432
P/J112
P/J3411
P/J111
P/J102
P/J401 P/J40
P/J902
P/J1401
P/J1501
P/J1502
P/J810 P/J820 P/J830 P/J840
P/J36
P/J11
P/J10 P/J101
P/J1302
P/J311P/J171
P/J172
P/J331
P/J17
P/J33
P/J28 P/J281
P/J29
P/J312
P/J281
P/J30
s6600-234

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
