Xerox Phaser 6600 Service Manual

General Information
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
1-60
Electrical Properties
Power Source
Two types of power source as follows are available for this printer, which are selected according to the
specifications.
• 110 M/C: ---voltage: 100-127VAC ±10% (90 ~ 140V), frequency: 50/60Hz ± 3Hz
• 220 M/C: ---voltage: 220-240VAC ±10% (198 ~ 264V), frequency: 50/60Hz ± 3Hz
Power Consumption
Power consumption in each operation mode at rated voltage input
Rush Current
When the power switch is turned on, the inrush current shall be maximum 50Amp (Cold start)/135Amp
(Hot start) at first 2.5msec, and 80Amp (120V/220V/240V) / 85Amp (100V) within 10msec.
Operation mode Phaser 6600 WorkCentre 6605
Power off 0 W 0 W
Printing 535 W 560 W
Ready 65 W 72 W
Sleep 4 W 6 W

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
