Xerox Phaser 6600 Service Manual

General Information
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
1-59
Functional Configuration
Functional configurations of the Phaser 6600 and WorkCentre 6605 printers are shown below.
Network
USB2.0
Wireless Network (Option)
Option
0HPRU\
+''
SFP Controller
Control Panel
>[3L[HO%LWPDS3DQHO@
Engine
IOT
Laser
Unit
0&8%RDUG
s6600-243
SFP
USB-
HUB
NCU
CCD LED Sensor Motor
IIT (Scanner)
DADF
Network (Rear)
USB2.0 (Rear)
Wireless Network (Option)
USB host 2.0 (Front)
(For USB Memory)
Option
0HPRU\
+''
MFP Controller
Control Panel
[4.3 inch Touch Panel]
Engine
IOT
PSTN/PBX
s6600-238
Laser
Unit
MCU Board
MFP

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
