Xerox Phaser 6600 Service Manual

Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-24
Sensor Test Parameter Table
Chain Link Component
010 200 Fusing Relay Enable
010 201 Fusing Fuse Sensor
041 300 Interlock, Side Cover
041 301 Interlock, Rear Cover
041 302 Front Cover Sensor
042 200 LVPS Fan Alarm
071 100 Bypass Tray No Paper Sensor
071 101 Tray1 No Paper Sensor
071 102 Bypass Tray Detect Sensor
071 103 Regi Sensor
071 104 Exit Sensor
071 105 Full Stack Sensor
071 109 Option Feeder1 Size Sensor0
071 110 Option Feeder1 Size Sensor1
071 111 Option Feeder1 Size Sensor2
071 112 Option Feeder2 Size Sensor0 (not in use)
071 113 Option Feeder2 Size Sensor1 (not in use)
071 114 Option Feeder2 Size Sensor2 (not in use)
071 115 Option Feeder1 No Paper Sensor
071 116 Option Feeder2 No Paper Sensor (not in use)
071 117 Option Feeder1 Path Sensor
071 118 Option Feeder2 Path Sensor (not in use)
071 200 Main Motor Alarm
071 201 Paper Transport Motor Alarm
071 202 Option Feeder1 Motor Alarm
071 203 Option Feeder2 Motor Alarm (not in use)
093 200 Developer Motor Alarm
094 202 Waste Toner Box Full Sensor
