Xerox Phaser 6600 Service Manual

Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-74
825 103 FAX_SET_PREFIX_NUM FaxSetting Prefix
Dial Number
UINT8*5
825 602 FAX_SET_LINE_MONI FaxSetting Line
Moniter Sound
Volume
0-3 0: OFF
1: Min
2: Middle
3: Max
825 635 FAX_SET_CAPAB_ECM FaxSetting ECM
Setting
0,1 0: Disable
1: Enable
825 701 FAX_SET_UI_FAX_SPEED On-Panel Fax
Communication
Speed
0-4 0 :2400
1: 4800
2: 9600
3: 14400
4: 33600
701 10 FAX_SET_FOWD_SET FaxSetting Fax
Receive Print
Transfer
0,2 0: Do Not Transfer
2: Always Transfer
701 11 FAX_SET_FOWD_PRT FaxSetting Print
Setting Upon Fax
Receive Print
Transfer
0,1 0: Do Not Print
1: Print
701 12 FAX_SET_FWD_ERR_PRT FaxSetting Print
Upon Fwd. Error
Print
0,1 0: Do Not Print
1: Print
820 001 DIAG_DIALLING_TYPE Dial Type 0-2
821 101 DIAG_SYS_MACHINE_MODE Operation Mode 0,1 Specify [1] to output
the monitor sound
from the speaker
upon fax
communication.
0: Normal Mode
1: Maintenance
Mode
Parameter List
Chain Link Parameter Name Range
Fac’y
Def’lt
Note

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
