Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-84
825 669 DIAG_SAVE_ERROR_RX_DATA Store Decode
Error Page
0,1
825 673 DIAG_DFAULT_JBIG_LRLTWO LRLTWO
(Reference Line)
Value
0,1
825 702 DIAG_EXTEL_HOOK_THRESH_0 Threshold Value
0 for External
Phone HOOK
Detection
0-255
825 703 DIAG_EXTEL_HOOK_THRESH_1 Threshold Value
1 for External
Phone HOOK
Detection
0-255
825 704 DIAG_EXTEL_HOOK_THRESH_2 Threshold Value
2 for External
Phone HOOK
Detection
0-255
825 705 DIAG_CAPAB_EXTEL_HOOK_SU
PPLEMENT
Support ETSI
Standard
(Enable/Disable
Start)
0,1 0: Disable
1: Enable
825 706 DIAG_EXTEL_HOOK_SUPPLEMN
T_VOLTHRESH
Support ETSI
Standard
(Voltage to
Decide External
Phone OFFHOOK)
10-20 10, 15, 20 (V)
950 001 DIAG_FORGET_ERROR_SECRET 0-255
950 002 DIAG_CODE_CHECK_SECRET 0-255
950 003 DIAG_PMQAT_BOARD_SECRET 0-255
950 004 DIAG_DONT_DEL_TXFILE 0,1
950 005 DIAG_DONT_PR_RCVFILE 0,1
950 006 DIAG_MON_SPEED_38400 0,1
950 007 DIAG_COMM_TIME_MEASURE 0,1
950 008 DIAG_WITHOUT_ICM 0,1
950 009 DIAG_COMM_PARAM 0,1
950 010 DIAG_EQM_READ 0,1
950 011 DIAG_AGCVAL_READ 0,1
Parameter List
Chain Link Parameter Name Range
Fac’y
Def’lt
Note
To Next Page
