Xerox Phaser 6600 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-99
050 112 MSI Paper Jam Detected
Zone MSI
Paper Jam
Open BypassTray
and Tray1,
remove paper.
1. Pull out
papers on the
Bypass Tray
2. Pull out
Bypass Tray
3. Pull out
Tray1
4. Remove
any jammed
paper
5. Push Tray1
back in
6. Push
Bypass Tray
back in
050 121 IOT Remain Zone
1T JAM
Paper Jam Detected
Zone 1T
Paper Jam
Open Tray1
and remove paper
PressOK to start
Open Tray1 &
Remove
paper
050 122 IOT Remain Zone
2T JAM
Paper Jam Detected
Zone 2T
Paper Jam
Open Tray2
and remove paper
Open Tray2 &
Remove
paper
Phaser 6600 Error Code List
Chain Link Error Error Details Control Panel Messages FIP location
