Xerox Phaser 6600 Service Manual

Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-118
016 610 Panel Destination
Mismatch (only
for Production
Line)
Tried to apply JP setting to
non-JP panel, or tried to
apply non-JP setting to JP
panel.
Control Panel Error 016-610
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Replace the
IP Board.
016 612 Invalid MAC
Address
MAC address is invalid
(only for production line)
Invalid MAC Address 016-612
Power Off/On the Printer.
If this failure occurs again, please
contact customer support.
Replace the
IP Board.
016 718 Memory Overflow Job exceeded memory
capacity. 016-718
Job canceled.
* Caution screen with [Close]
button
Replace the
IP Board.
016 720 PDL Error Print Job Processing Error 016-
720
Job canceled.
* Caution screen with [Close]
button
Replace the
IP Board.
016 737 DOWNLOAD
FORMAT ERROR
Download file format is
invalid.
File Format Error 016-737
Job canceled.
* Caution screen with [Close]
button
Replace the
IP Board.
016 741 DOWNLOAD
PROTECT ERROR
Performed FW download
although FW update is
prohibited by panel
settings.
File Protection Error 016-741
Job canceled.
* Caution screen with [Close]
button
Replace the
IP Board.
016 742 DOWNLOAD ID
ERROR
Download file ID is invalid. Invalid File ID 016-742
Job canceled.
* Caution screen with [Close]
button
Replace the
IP Board.
016 743 DOWNLOAD
RANGE ERROR
At download, write-in
destination address is
invalid. Range check error.
Range Check Error 016-743
Job canceled.
* Caution screen with [Close]
button
Replace the
IP Board.
WorkCentre 6605 Error Code List
Chain Link Error Error Details Control Panel Messages
FIP
location

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
