Xerox Phaser 6600 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-193
072-100 IOT Tray2 Misfeed JAM
072-101 IOT Path2 SNS On JAM
Step Check Yes No
Possible causative parts:
• Path Sensor [550 Option Main Feed Assembly] (PL10.2.1)
• 550 Option Regi Clutch Assembly (PL10.2.2)
• 550 Option Feed Clutch Assembly (PL10.1.8)
• 550 Option Drive Assembly (PL10.1.9)
• Feed Roller Assembly (PL10.2.3)
• Tray Retard Holder Assembly (PL10.3.3)
• C2 Size Harness Assembly (PL10.1.14)
• C2 Turn Harness Assembly (PL10.1.15)
• Feeder Motor Harness Assembly (PL10.1.16)
• 550 Option Feeder Board (PL10.1.10)
• MCU Board (PL18.1.13)
1 Check the Tray 2 installation
Is Tray 2 installed properly?
Go to step 2. Install Tray 2
properly.
2 Check the paper path
Are there any foreign objects, or paper pieces, etc. on the
paper path?
Remove the
foreign objects,
or paper pieces,
etc.
Go to step 3.
3 Check the paper feed roller
Is the paper feed roller (the roller on the possible causative
parts list) installed properly?
Go to step 4. Reinstall the
paper feed roller.
4 Check the paper feed roller
Is the paper feed roller (the roller on the possible causative
parts list) deformed or worn out?
Replace the
paper feed roller.
Go to step 5.
5 Check the Path Sensor operation
Execute Digital Input diagnostic test 071-117, and check the
Path Sensor operation.
Does the Path Sensor function normally?
Go to step 6. Refer to
page 2-213.
6 Check the 550 Option Regi Clutch Assembly operation
Execute Digital Output diagnostic test 071-020, and check
the 550 Option Regi Clutch Assembly operation.
Does the 550 Option Regi Clutch Assembly function
normally?
Go to step 7. Refer to
page 2-214.
7 Check the 550 Option Feed Clutch Assembly operation
Execute Digital Output diagnostic test 071-022, and check
the 550 Option Feed Clutch Assembly operation.
Does the 550 Option Feed Clutch Assembly function
normally?
Go to step 8. Refer to
page 2-216.

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
