Xerox Phaser 6600 Service Manual

Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-196
075-910 MSI (Bypass Tray) Detached
Step Check Yes No
Possible causative parts:
• Bypass Tray No Paper Sensor (PL13.2.4)
• Bypass Tray Cover Assembly (PL13.3.2)
• Bypass Tray Harness Assembly (PL13.2.5)
• MCU Board (PL18.1.13)
1 Check the Bypass Tray installation
Is the Bypass Tray installed properly?
Go to step 2. Install the
Bypass Tray
properly.
2 Check the Bypass Tray Cover Assembly
Is the Bypass Tray Cover Assembly broken?
Replace the
Bypass Tray
Cover Assembly.
Go to step 3.
3 Check the Bypass Tray No Paper Sensor operation
Execute Digital Input diagnostic test 071-102, and check the
Bypass Tray No Paper Sensor operation.
Does the Bypass Tray No Paper Sensor function normally?
Replace the MCU
Board.
Go to step 4.
4 Check the connections between Bypass Tray No Paper Sensor
and the MCU Board
Check the connection between the Bypass Tray No Paper
Sensor and the MCU Board.
Are P/J211 and P/J21 connected securely?
Go to step 5. Connect P/J211
and P/J21
securely.
5 Check the Bypass Tray Harness Assembly continuity.
Is each cable of P/J211<=>P/J21 continuous?
Go to step 6. Replace the
Bypass Tray
Harness
Assembly.
6 Check the power to the Bypass Tray No Paper Sensor
(+5 VDC)
Check if the voltage between the MCU Board ground and the
P/J21- 1 pin is about +5 VDC.
Replace the
Bypass Tray No
Paper Sensor.
Refer to
page 2-223.

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
