Error Troubleshooting
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
2-200
077-304 IOT Cover Rear Open
091-400 IOT Waste Toner Box Near Life
091-911 IOT Waste Toner Box Life Over
Step Check Yes No
Possible causative parts:
• Rear Interlock Switch (PL19.1.21)
• LVPS (PL18.1.34)
1 Check the Rear Interlock Switch operation
Execute Digital Input diagnostic test 041-301, and check the
Rear Interlock Switch operation.
Does it function normally?
Replace the MCU
Board.
Go to step 2.
2 Check the Rear Interlock Switch connection
Check the connection between the Rear Interlock Switch and
the LVPS.
Is P/J41 connected securely?
Go to step 3. Connect P/J41
securely.
3 Check after replacing the Rear Interlock Switch
Replace the Rear Interlock Switch.
Does the error still occur?
Replace the LVPS. Finished.
Step Check Yes No
Possible causative parts:
• Toner Full Sensor (PL4.1.17)
• MCU Board (PL18.1.13)
1 Check the Toner Full Sensor operation
Execute Digital Input diagnostic test 094-202, and check the
Toner Full Sensor operation.
Does it function normally?
Replace the MCU
Board.
Go to step 2.
2 Check the Toner Full Sensor connection
Check the connection between the Toner Full Sensor and the
MCU Board.
Are P/J203 and P/J29 connected securely?
Go to step 3. Connect P/J203
and P/J29
securely.
3 Check the power to the Toner Full Sensor (+5 VDC)
Check if the voltage between the MCU Board ground and the
P/J29-20 pin is about +5 VDC.
Replace the
Toner Full Sensor.
Refer to
page 2-223.
To Next Page
