Xerox Phaser 6600 Service Manual

Error Troubleshooting
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
2-219
Bypass Tray Feed Solenoid (PL13.2.9)
8 Check the PWBA Assembly FEED connection
Check the connection between the PWBA Assembly FEED
and the MCU Board.
Are P/J419, DP/J271, and P/J27 connected securely?
Replace the
Drawer 1 Feeder
Harness
Assembly
and the
Main Harness
Assembly.
Connect P/J419,
DP/J271, and
P/J27 securely.
Step Check Yes No
Possible causative parts:
• Bypass Tray Feed Solenoid (PL13.2.9)
• Bypass Tray Harness Assembly (PL13.2.5)
• MCU Board (PL18.1.13)
1 Check the Bypass Tray Feed Solenoid operation
Execute Digital Output diagnostic test 071-007, and check
the Bypass Tray Feed Solenoid operation.
Does the Bypass Tray Feed Solenoid function normally?
Replace the MCU
Board.
Go to step 2.
2 Check the Bypass Tray Feed Solenoid connection
Check the connection between the Bypass Tray Feed
Solenoid and the MCU Board.
Are P/J214 and P/J21 connected securely?
Go to step 3. Connect P/J214
and P/J21
securely.
3 Check the continuity between the Bypass Tray Feed Solenoid
and the MCU Board
Is each cable of P/J214<=>P/J21 continuous?
Go to step 4. Replace the
Bypass Tray
Harness
Assembly.
4 Check the power to the Bypass Tray Feed Solenoid (+24 VDC)
Close the interlock switch(es), and check if the voltage
between the MCU Board ground and the P/J21-9 pin is about
+24 VDC.
Replace the
Bypass Tray Feed
Solenoid.
Refer to
“+24 VDC Power
FIP” on
page 2-222.
Step Check Yes No

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
