Xerox Phaser 6600 Service Manual

Image Quality
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
3-25
Images are skewed
Possible causative parts
• Transfer Roller (PL14.1.99)
• Fuser Assembly (PL7.1.1)
• Transfer Belt Assembly (PL6.1.1)
• Retard Holder Assembly (PL13.3.14)
• Feed Roller Assembly (PL13.2.10)
• Retard Holder Assembly (PL10.3.3)
• TA1 Roller Assembly (PL13.1.2)
• TA2 Roller Assembly (PL13.1.3)
• Regi Chute Assembly (PL15.2.1)
• Exit Roller Assembly (PL17.1.14)
Action Yes No
1 Adjust the paper guides properly.
Does this solve your problem?
The task is
complete.
Go to action 2.
2 Install the Transfer Belt Assembly according to an appropriate
procedure.
Does this solve your problem?
The task is
complete.
Go to action 3.
3 Check the paper humidity conditioning effect.
Load the unopened (or stored and sealed under humidity control)
and recommended paper, and then perform a test print.
Is the image printed correctly?
The task is
complete.
Go to action 4.
4 Check the paper type setting.
Is the paper type setting corresponding with the paper printed?
Go to action 5. Set the correct
paper type.
5 Check the paper transfer path.
Are there any dirt or foreign substances on the paper transfer path
between the paper entrance and the paper exit?
Remove the
foreign
substance.
Go to action 6.
6 Check the paper feed path roller.
Is the roller on the paper feed path not dirty, damaged, or worn,
and does it work correctly?
Also, is the roller installed correctly?
Go to action 7. Clean or
replace the
corresponding
roller, and
reinstall it.
7 Check the installation status of the Transfer Roller.
Is Transfer Roller installed correctly?
Go to action 8. Reinstall
Transfer Roller.
8 Check the installation status of the Fuser Assembly.
Is the Fuser Assembly installed correctly?
Contact Xerox
Te ch ni ca l
Support.
Reinstall the
Fuser Assembly.
Skew 2

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
