Xerox Phaser 6600 Service Manual

Parts Lists
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
5-25
Parts List 9.1 Tray
Item Name Part Number
1 Cassette Assy 550 IOT (with2-30) (550-sheet Paper Tray) 050K66514
2 Plate Assy Bottom (Bottom Plate Assembly) —
3 Holder Assy Retard CST (with4-7) (Tray Retard Holder Assembly) —
4 Roll Assy Feed (Feed Roller Assembly) —
5Clutch Friction RTD Z —
6 Shaft Retard CST (Tray Retard Shaft) —
7Holder Retard CST —
8 Guide Assy Side L 550 (Left Side Guide Assembly) —
9 Guide Assy Side R 550 (Right Side Guide Assembly) —
10 Gear Pinion —
11 Cover BTM Lock 550 —
12 Rack BTM Lock 550 —
13 Gear BTM Lock Pinion —
14 Gear Lever BTM Lock —
15 Lever BTM Lock —
16 Gear 40 BTM Lock —
17 Spring BTM Lock —
18 Spring Lock PB —
19 Actuator Lock PB L —
20 — —
21 Spring BTM UP 550 A4 —
22 Holder Spring Retard MSI (Bypass Tray Retard Spring Holder) —
23 Spring Retard CST —
24 Rack Lift UP PB 550 —
25 Housing Base 550 —
26 Lever Ext End 550 —
27 Guide Assy End 550 Opt (550 Option End Guide Assembly) —
28 Housing End 550 —
29 — —
30 Handle CST 550 —

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
