Xerox Phaser 6600 Service Manual

Parts Lists
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
5-35
Parts List 13.2 Bypass Tray
Item Name Part Number
1 Frame Assy MSI (with2-26) (Bypass Tray Frame Assembly) 801K47622
2 Frame MSI (Bypass Tray Frame) —
3 Bracket No Paper MSI (Bypass Tray No Paper Bracket) —
4
MSI Detect Sensor (Bypass Tray No Paper Sensor
)
—
5 Harness Assy MSI (Bypass Tray Harness Assembly) —
6 Guide Harness MSI (Bypass Tray Harness Guide) —
7 Spring Feed —
8 Gear Feed MSI (Bypass Tray Feed Gear) —
9 Solenoid Feed MSI (Bypass Tray Feed Solenoid) —
10 Roll Assy Feed (Feed Roller Assembly) 059K78701
11 Cam MSI L (Left Bypass Tray Cam) —
12 Roll Core —
13 Holder Feed —
14 Shaft Feed MSI (Bypass Tray Feed Shaft) —
15 Cam MSI R (Right Bypass Tray Cam) —
16 Guide Support R (Right Support Guide) —
17 Guide Support L (Left Support Guide) —
18 Arm R (Right Arm) —
19 Spring NF (NF Spring) —
20 Arm L (Left Arm) —
21 Bracket Gear (Gear Bracket) —
22 Follower R (Right Follower) —
23 Follower L (Left Follower) —
24 Guide Bottom R (Right Bottom Guide) —
25 Slide Bottom (Bottom Slide) —
26 Guide Bottom L (Left Bottom Guide) —
98 Kit Roll Assy (with10-15) (Roller Kit Assembly) 604K73910
99 Kit Solenoid Assy (with7-9) (Solenoid Kit Assembly) 604K73921

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
