Parts Lists
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
5-37
Parts List 13.3 MSI
Item Name Part Number
1 Tray Assy MSI Main (with2-19) (Bypass Tray Assembly) 050K66572
2 Cover Assy MSI (Bypass Tray Cover Assembly) 848K51102
3 Spring Damper (Damper Spring) —
4 Cover MSI Under (Bypass Tray Lower Cover) —
5 Chute Assy MSI (with6-19) (Bypass Tray Chute Assembly) 054K46612
6 Bar MSI Front (Bypass Tray Front Bar) —
7 Spring No Paper (No Paper Spring) —
8 Actuator No Paper (No Paper Actuator) —
9 Roll Pinch MSI (Bypass Tray Pinch Roller) —
10 Spring Pinch TA1 (TA1 Pinch Spring) —
11 Spring Pinch TA2 (TA2 Pinch Spring) —
12 Chute Retard (Retard Chute) —
13 Spring Retard MSI (Bypass Tray Retard Spring) —
14 Holder Assy Retard (Retard Holder Assembly) —
15 Plate Assy Bottom (Bottom Plate Assembly) —
16 Latch MSI L (Left Bypass Tray Latch) —
17 Latch MSI R (Right Bypass Tray Latch) —
18 Spring Latch MSI (Bypass Tray Latch Spring) —
19 Chute MSI (Bypass Tray Chute) —
98 Kit Roll Assy Separater (with13,14) (Separator Roller Assembly Kit) 604K74440
99 Kit Roll Pinch (with9-11) (Pinch Roller Kit) 604K73940
