Xerox Phaser 6600 Service Manual

Parts Lists
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
5-40
Parts List 15.1 Registration / Feeder
Item Name Part Number
1— —
2 Chute Dup Upper (Upper Duplex Chute) —
3 Chute Assy Dup Regi (Regi Duplex Chute Assembly) —
4 Chute Regi Lower —
5 Chute Regi Opt 550 —
6 Chute Assy Upper IBT (Upper Transfer Belt Chute Assembly) 054K46650
7— —
8 Clutch Assy Regi (Regi Clutch Assembly) —
9 Guide Tray L (Left Tray Guide) —
10 Stopper CST (Cassette Stopper) —
11 Gear Idle 28 —
12 Gear Idle 25 —
13 Cover Gear MSI —
14 Guide Tray R (Right Tray Guide) —
15 — —
98 Kit Chute Dup Assy (with2,3) (Duplex Chute Assembly Kit) 054K46640
99A Kit Chute Regi High Assy DN(with2-5,PL15.2) (Upper Regi
Chute Assembly Kit DN)
604K77750
99B Kit Chute Regi High Assy N(with2-5,PL15.2) (Upper Regi
Chute Assembly Kit N)
604K77760

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
