Xerox Phaser 6600 Service Manual

Parts Lists
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
5-44
Parts List 17.1 Exit
Item Name Part Number
1 Kit Assy Exit (with2-18,22) (Exit Kit Assembly) 054K49180
2Plate Earth Exit B —
3Plate Earth Exit A —
4Actuator Exit B —
5 Spring Actuator B —
6Actuator Exit A —
7 Spring Actuator A —
8Chute Exit Upper S3 —
9Eliminator Exit —
10 Actuator Full Stack —
11 Sensor-Photo Int (Interlock Photo Sensor) —
12 Chute Exit Lower S3 —
13 Bearing-Exit —
14 Roll Assy Exit (Exit Roller Assembly) —
15 Gear Exit —
16 Roll-Pinch —
17 Spring-Pinch —
18 Harness Assy Exit Snr (Exit Sensor Harness Assembly) —
19 — —
20 Cover Exit Tray (Exit Tray Cover) —
21A Drive Assy Exit DN (Exit Drive Assembly - DN) 007K18762
21B Drive Assy Exit N (Exit Drive Assembly - N) 007K18772
22 Flapper Exit —
23 Harness Assy Snr (Sensor Harness Assembly) —

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
