Xerox Phaser 6600 Service Manual

Parts Lists
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
5-46
Parts List 18.1 Phaser 6600 Electrical (1/2)
Item Name Part Number
1— —
2 Guide_ Harnness_ Top —
3— —
4 Guide_ Harnness_ Exit —
5 Cover Harness Top —
6 Guide Harness Top L (Left Top Harness Guide) —
7 Guide_ Harness_ Erase_ CRM —
8 Housing _ Assy_ Charge_ Deve (Developer Charge Housing Assembly) —
9 Housing_ Assy_ Charge_ Deve_ Out (Outer Developer Charge Housing Assembly) —
10 Guide Harness Video (Video Harness Guide) —
11 Guide Harness L (Left Harness Guide) —
12 Plate MCU (MCU Plate) —
13 PWBA MCU (MCU Board) 960K67961
14 PWBA HVPS XD (Development HVPS Board) 105K26092
15 Plate Earth HV (HV Ground Plate) —
16 Housing Assy Gnd Fusing (Fuser Ground Housing Assembly) —
17 Varistor, NVD10UCD1100 —
18 Plate Window —
19 Plate ESS Top —
20 Plate_ ESS_ Bottom —
21 Kit Package Hard Disk —
22 PWBA ESS (IP Board) 960K60494
23 Plate ESS Front (Front IP Board Plate) —
24 Plate ESS Rear (Rear IP Board Plate) —
25 — —
26 — —
27 Kit Packaging Wireless (Wireless Kit) —
28 PWBA HVPS TR (Transfer HVPS Board) 105K26102
29 Guide_ Harness_ PH —
30
Housing_ Assy_ Wire_ TR_IN (
Inner Transfer Wire Housing Assembly)
—

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
