Xerox Phaser 6600 Service Manual

Wiring
Xerox Internal Use Only Phaser 6600 and WorkCentre 6605
Service Manual
7-13
271 F-112/I-182 Connects Feeder Drawer 1 Harness Assembly and Main Harness Assembly
271 I-182 Connects Feeder Drawer 1 Harness Assembly and Main Harness Assembly
281 E-152 Connects Fuser and Heater Harness Assembly
311 E-108 Connects Main Motor and Top Harness Assembly
312 E-111 Connects Paper Transport Motor and Top Harness Assembly
331 E-109 Connects Deve Motor and Drive Harness Assembly
392 E-126 Connects CST Feed Clutch and Regi Harness Assembly
401 D-162 Connects IP Board and Top Harness Assembly
419 G-183 Connects IP Board and Top Harness Assembly
420 G-183 Connects 550 Option Feeder Board and Feeder Drawer 1 Harness Assembly
421 F-183 Connects 550 Option Feeder Board and C2 Turn Harness Assembly
422 F-183 Connects 550 Option Feeder Board and C2 Size Harness Assembly
423 G-183 Connects 550 Option Feeder Board and Feeder Motor Harness Assembly
431 H-140 Connects Laser Unit and Top Harness Assembly
501 C-157 Connects LVPS and Top Harness Assembly
503 C-157 Connects LVPS and Main Fan
507 H-157 Connects LVPS and Top Harness Assembly
508 H-157 Connects LVPS and Top Harness Assembly
509 B-158 Connects LVPS and Top Harness Assembly
810 A-164 Connects IP Board and USB Hub Board
820 E-107 Connects USB Hub Board and IP Board
830 E-107 Connects USB Hub Board and Control Panel Assembly
902 C-166 Connects IP Board and FAX Board
1302 D-165 Connects IP Board and Speaker
1401 A-162 Connects IP Board and Scanner Assembly
1501 D-162 Connects IP Board and Scanner Assembly
1502 C-162 Connects IP Board and Scanner Assembly
1821 C-173 Connects Transfer HVPS and HVPS Harness Assembly
4201 E-184 Connects C2 Turn Clutch and C2 Turn Harness Assembly
4202 E-184 Connects No Paper Harness Assembly and C2 Turn Harness Assembly
4203 D-182 Connects C2 No Paper Sensor and No Paper Harness Assembly
P/J Coordiates Remarks

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
