Xerox Phaser 6600 Service Manual

Wiring
Phaser 6600 and WorkCentre 6605 Xerox Internal Use Only
Service Manual
7-50
Signal line name Description
FEED TRAY SENS
FEED RXD
FEED TXD
Control signal of the 550 Option Feeder Board
TURN ROLL CLUTCH ON ON/OFF signal of the Turn Roll Clutch
TRAY PAPER SENSED SIGNAL Detect signal of paper inside the optional tray by the C2 No
Paper Sensor
REGI PAPER SENSED SIGNAL Detect signal of paper in the Registration section of the optional
tray by the C2 Regi Sensor
FEED ROLL CLUTCH ON ON/OFF signal of the C2 Feed Clutch
SIZE3
SIZE2
SIZE1
Detect signal of a paper size inside the optional tray by the 550
Size Switch Assembly
OP FEED MOTOR ON
OP FEED MOTOR ALARM
OP FEED MOTOR CLOCK
OP FEED MOTOR GAIN
Drive control signal of the Option Feeder Motor

Xerox Phaser 6600 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	9 s
Time to first page (color, normal)	10 s
Print speed (black, normal quality, A4/US Letter)	36 ppm
Maximum duty cycle	80000 pages per month
Number of print cartridges	-
Internal memory	256 MB
Processor frequency	533 MHz
Maximum internal memory	768 MB
Sound pressure level (printing)	53 dB
Total input capacity	700 sheets
Total output capacity	250 sheets
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels
ISO A-series sizes (A0...A9)	A4
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	535 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Weight	25500 g
Dimensions (WxDxH)	429.26 x 487.68 x 383.54 mm
