Xerox WorkCentre 5230A User Manual

7 CentreWare Internet Services
174
Job Flow Sheets Common Attributes
The following table shows the information fields on the [Job Flow Sheets Common
Attributes] page.
Print
The following table shows the information fields on the [Print] page.
Edit Job Flow Sheet Displays the [Job Flow Sheets Common Attributes] page where
you can edit the selected job flow sheet.
NOTE: This button becomes active only when logged in as the
System Administrator.
Create Job Flow
Sheet
Displays the [Job Flow Sheets Common Attributes] page where
you can create a new job flow sheet.
NOTE: This button becomes active only when logged in as the
System Administrator.
Job Flow Sheet Name Enter or change the name of the selected job flow sheet.
Description Enter or change the description of the job flow sheet.
Job Flow Displays the type of command set for the job flow sheet.
Total Destinations Displays the number of destinations defined in the job flow sheet.
Sheet Type Displays the access type ([Personal] or [Shared]) of the job flow
sheet. This item is displayed only when the Authentication feature
is enabled.
Keyword Enter a keyword to be used when searching the job flow sheet.
The keyword can be up to 12 characters.
Edit Job
Flow
Sheet
Edit
Destination
Select a command to assign to the job flow sheet from [Print],
[Send as Fax], [Send as Internet Fax], [Send as E-mail], [FTP
Transfer], or [SMB Transfer]. Then click the [Edit Job Flow Sheet]
button to display a page where you can configure the selected job
flow sheet command.
Job Flow Sheet Name Displays the name of the job flow sheet.
Paper Supply Select the paper tray for the job flow sheet.
Output Destination Select the output paper tray.
Quantity Specify the number of printouts.
2 Sided Printing Select 1 sided or 2 sided output.
Staple Specify the staple position and the number of places to staple.
Hole Punch Specify the hole-punch position and the number of holes to
punch.

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
