Send as Fax
The following table shows the information fields on the [Send as Fax] page.
Send as Internet Fax
The following table shows the information fields on the [Send as Internet Fax] page.
Job Flow Sheet Name Displays the name of the job flow sheet.
Name Enter the recipient’s name.
Recipient Address Enter the recipient’s address.
Line Type Displays the line type: [Outside Line].
Starting Rate Select the fax communication mode from [G3 Auto] and [Forced
4800 bps].
Mailbox Number Enter the mailbox number.
Mailbox Passcode Enter the mailbox passcode.
Relay Broadcast Select whether to enable relay broadcasting.
Print at Relay Station Select whether to enable printing at the relay station.
NOTE: This setting is valid only when the [Relay Broadcast]
check box is selected.
Relay Station
ID/Broadcast
Recipients
Enter the speed dial codes of the relay station and relay
broadcast destinations, separating each dial code with a comma.
The first dial code you enter will be the code for the relay station.
You can register up to 21 relay broadcast destinations.
The dial code for the relay station must be a number between 0
and 99.
Enter the dial codes for the relay broadcast destinations as
follows:
• When entering an individual code, enter it between 0 and 99.
• When entering all codes, enter “**”.
• When entering all codes between n0 to n9 (for example, 20 to
29), enter “n*”.
• When entering a group code, enter “#n” (for example, #1 when
entering the group code 1).
NOTE: When the [Relay Broadcast] check box is not selected,
this item becomes inactive and cannot be configured.
F Code Enter the F code within 20 digits using numbers, # (number
signs), and * (asterisks).
Password (F Code
Communication)
Enter the password for the F code within 20 digits using numbers,
# (number signs), and * (asterisks).
Job Flow Sheet Name Displays the name of the job flow sheet.
Recipient Name 1 - 10 Enter the name of the recipient using up to 36 characters. You can
enter the names of up to 10 recipients.
Recipient Address 1 -
10
Enter the address of the recipient using up to 128 characters. You
can enter the addresses of up to 10 recipients.
Message Enter the body message of the e-mail.
Internet Fax Profile Select the TIFF profile of Internet Fax from [TIFF-S], [TIFF-F], and
[TIFF-J].
Header Select the check box if adding the Internet Fax header at the top of
scanned images.

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
