Xerox WorkCentre 5230A User Manual

7 CentreWare Internet Services
228
Security 802.1x Allows you to set up the 802.1 authentication feature.
Enable IEEE 802.1x
Select whether or not to enable IEEE 802.1x
authentication.
Authentication Method
Specify the IEEE 802.1 x authentication method.
Login Name (Device Name)
Enter a user name for IEEE 802.1 authentication.
Password
Enter the password for the user name.
Retype Password
Re-enter the password for verification.
Certificate Validation
Select whether or not to validate the server certificate
when [Authentication Method] is [PEAP/MS-CHAPv2].
SSL/TLS
Settings
Allows you to configure SSL/TLS communication.
HTTP - SSL / TLS Communication
Select to enable HTTPS SSL/TLS communication.
HTTPS - SSL/TLS Communication Port Number
Enter the number of the port to be used for HTTPS-
SSL/TLS communication.
LDAP - SSL/TLS Communication
Select to enable LDAP SSL/TLS communication.
S/MIME Communication
Select to use a certificate for e-mail
transmission/reception via S/MIME communication.
This check box becomes active only when a certificate
for S/MIME communication is registered on the
machine.
Verify Remote Server Certificate
Select to verify the validity of server certificates sent
from the SSL/TLS server during SSL/TLS
communication.
S/MIME Settings Message Digest Algorithm
Select a message digest algorithm from [SHA1] and
[MD5].
Message Encryption Method
Select the encryption method to use when encrypting
e-mail messages sent from the machine.
Certificate Auto Store
Select the check box to automatically save S/MIME
certificates when they are attached to e-mails sent
from the addresses registered in the Address Book.
Receive Untrusted E-mail
Select the check box if do not want to receive untrusted
e-mails, such as those without a certificate.
Digital Signature - Outgoing E-mail
Select whether to always add a digital signature to
outgoing e-mails.
Receive Untrusted Internet Fax
Select the check box if you do not want to receive
untrusted Internet faxes, such as those without a
certificate.
Digital Signature - Outgoing Internet Fax
Select whether to always add a digital signature to
outgoing Internet faxes.
Feature Setting items

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
