Xerox WorkCentre 5230A User Manual

Fault Codes
395
016-554 An Authentication Agent error occurred. The login name or password for
obtaining domain user information was not correct. Enter the correct login name
and password.
016-555 A timeout occurred while Authentication Agent was to be connected to the
database or to Active Directory. Check if Authentication Agent is able to be
connected to the database or to Active Directory. For more details, refer to the
manual provided with Authentication Agent.
016-556 A timeout occurred, because the database connected to Authentication Agent
was overloaded. Wait for a while, and then try again. If the problem persists,
check the status of Authentication Agent. For more details, refer to the manual
provided with Authentication Agent.
016-557 An error occurred on Authentication Agent. Check the status of Authentication
Agent. For details, refer to the manual provided with Authentication Agent.
016-558 The machine received an unknown error from Authentication Agent. Contact the
Xerox Welcome Center.
016-559 A Remote Download parameter error occurred. Check if the parameters used to
access the Remote Download server, are set correctly.
016-560 A communication error occurred between Authentication Agent and the
machine. Check the network cable connection and Authentication Agent
settings. Also print a Configuration Report, and if a DNS address is set under
“Server Name/IP Address”, check if the DNS server is working.
016-562 The database for temporary users on Active Directory or Authentication Agent
stores multiple entries with the same IC card information. Modify the entries so
that the temporary user information is not duplicated in the database.
016-564 A Remote Download server authentication error occurred. Check the login
name and password to access the Remote Download server. If the problem
persists, contact the Xerox Welcome Center.
016-569 An error occurred on Authentication Agent. Contact the Xerox Welcome Center.
016-570 The job ticket memory space is not sufficient. Increase the memory space in the
System Administration mode, reboot the machine, and then submit a job.
016-571 The job ticket contains invalid parameter values. Correct the parameter values,
and then submit a job.
016-572 The paper type, size, weight, or color specified in the job ticket is not supported
by the machine.
016-573 The machine could not parse syntax in the job ticket. Check if the application
that generated the job ticket is correctly installed and working. Also check if the
version of the application is compatible with the machine.
016-574 The machine failed to transfer data via FTP using the Scan to PC service
because the host or server name of the FTP server could not be resolved.
Check the connection to the DNS server. Check if the FTP server name is
registered correctly on the DNS server.
016-575 The machine failed to transfer data via FTP using the Scan to PC service
because the DNS server address was not registered. Specify the correct DNS
server address. Or, specify the destination FTP server using its IP address.
Code Description and Remedy

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
