Xerox WorkCentre 5230A User Manual

Fault Codes
425
036-788
036-789
The polling feature was to be used, but the target machine did not store the
documents to be polled. Check the target machine, and try again.
036-790
036-791
Communication failed due to an invalid request. Check the procedure in the
User Guide and perform the operation again.
036-792
036-793
Refer to 034-508.
036-795 The remote copy function (to make multiple copies of a received document) is
not supported on the destination machine. Check if the remote copy function is
supported on the destination machine.
036-796 The general fax mode was used, because the remote copy function (to make
multiple copies of a received fax document) was not supported on the
destination machine.
036-797
036-798
036-799
Refer to 034-508.
041-210
041-211
An error occurred in the tray module. Switch off the machine, and then switch it
on again. Contact the Xerox Welcome Center if the problem persists.
047-211 A hardware problem occurred in the paper output assembly. Switch off the
machine, and then switch it on again. Contact the Xerox Welcome Center if the
problem persists.
047-212 An error occurred in the Offset Stacking Module. Switch off the machine, and
then switch it on again. Contact the Xerox Welcome Center if the problem
persists.
047-213 An error occurred in the Finisher. Switch off the machine, and then switch it on
again. Contact the Xerox Welcome Center if the problem persists.
047-214 An error occurred in the Duplex Module. Switch off the machine, and then switch
it on again. Contact the Xerox Welcome Center if the problem persists.
047-215 A communication error occurred between the main unit and the Exit Module.
Switch off the machine, and then switch it on again. Contact the Xerox Welcome
Center if the problem persists.
047-216 An error occurred in the Finisher. Switch off the machine, and then switch it on
again. Contact the Xerox Welcome Center if the problem persists.
047-217 A communication error occurred between the main unit and the High Capacity
Feeder. Switch off the machine, and then switch it on again. Contact the Xerox
Welcome Center if the problem persists.
047-218 A communication error occurred between the main unit, and the Two Tray
Module or the High Capacity Tandem Tray. Switch off the machine, and then
switch it on again. Contact the Xerox Welcome Center if the problem persists.
062-210 The document feeder malfunctioned. Contact the Xerox Welcome Center.
062-211 An error occurred in the document feeder. Contact the Xerox Welcome Center.
062-277 A communication error occurred between the scanner and the feeder. Contact
the Xerox Welcome Center.
062-394 Data could not be written in memory space. Switch off the machine, and then
switch it on again.
Code Description and Remedy

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
