Xerox WorkCentre 5230A User Manual

15 Problem Solving
426
062-790 The scanned document is copy-prohibited. Refer to Illegal Copies in the Before
Using the Machine chapter in the User Guide, to verify the types of documents
that can be copied.
071-210
071-211
An error occurred when Tray 1 was used. Switch off the machine, and then
switch it on again. Contact the Xerox Welcome Center if the problem persists.
072-210
072-211
An error occurred when Tray 2 was used. Switch off the machine, and then
switch it on again. Contact the Xerox Welcome Center if the problem persists.
073-210
073-211
An error occurred when Tray 3 was used. Switch off the machine, and then
switch it on again. Contact the Xerox Welcome Center if the problem persists.
074-210
074-211
An error occurred when Tray 4 was used. Switch off the machine, and then
switch it on again. Contact the Xerox Welcome Center if the problem persists.
077-211 An error occurred with the Two Tray Module or the High Capacity Tandem Tray.
Switch off the machine, and then switch it on again. Contact the Xerox Welcome
Center if the problem persists.
077-215 An error occurred when the Two Tray Module was used. Switch off the machine,
and then switch it on again. Contact the Xerox Welcome Center if the problem
persists.
078-210 An error occurred when Tray 1 of the High Capacity Tandem Tray was used.
Switch off the machine, and then switch it on again. Contact the Xerox Welcome
Center if the problem persists.
078-211 An error occurred when Tray 2 of the High Capacity Tandem Tray was used.
Switch off the machine, and then switch it on again. Contact the Xerox Welcome
Center if the problem persists.
078-212 An error occurred in the High Capacity Feeder. Switch off the machine, and then
switch it on again. Contact the Xerox Welcome Center if the problem persists.
078-213
078-214
Tray 5 (Bypass) malfunctioned. Switch off the machine, and then switch it on
again. If the problem persists, contact the Xerox Welcome Center.
078-250 An error occurred in the High Capacity Feeder. Switch off the machine, and then
switch it on again. Contact the Xerox Welcome Center if the problem persists.
081-799 The e-mail to fax job was cancelled. The fax destination may be incorrect.
Check the number, and try again.
112-700 The hole punch waste container is full. Empty the container.
For information on how to empty the hole punch waste container, refer to
Emptying the Hole Punch Waste Container (Optional) on page 37 .
116-220 The machine failed to move onto the Download mode. Contact the Xerox
Welcome Center.
116-392 The Printer or PostScript kit is attached to an improper slot on the controller
board. Attach the Printer or PostScript kit to the correct slot.
116-701 Unable to print double-sided due to insufficient memory. Check if memory is
installed correctly. If the problem persists, contact the Xerox Welcome Center.
116-702 Data was printed using a substitute font. Check the print data.
116-703 An error occurred during PostScript processing. Check the print data, or disable
bi-directional communication on the print driver.
116-713 The data was divided because the hard disk ran out of space. Delete
unnecessary data from the hard disk.
Code Description and Remedy

Xerox WorkCentre 5230A Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Time to first page (black, normal)	4.3 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Power supply type	AC
Dimensions (WxDxH)	640 x 652 x 1113 mm
Power requirements	220 – 240V, 50/60 Hz
Printer management	SNMPv1, SNMPv2c, SMTPv3, TCP/IP, IP
Networking features	Fast Ethernet
All-in-one functions	Copy, Scan
Standard media sizes	89 x 98.4mm - 297 x 420mm
Maximum internal memory	0.768 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7 Mac OS X 10.3 – 10.5 AIX 5Iv5.3 HP UX 11.0, 11i v2 Solaris 8/9/10 Linux Fedora Core 1/5 RedHat Enterprise Linux 4 SUSE x10
Dimensions (W x D x H) (imperial)	25.2 x 25.7 x 43.8 \
Acoustic power emissions (active, print, copy or scan)	72/38 dB
Scanner type	Flatbed scanner
Input color depth	24 bit
Maximum scan area	297 x 432 mm
Image formats supported	JPG, TIF
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Copy speed (black, normal quality, A4)	30 cpm
Total input capacity	1100 sheets
Total output capacity	500 sheets
Maximum input capacity	5100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Internal memory	512 MB
Processor family	PowerPC
Internal storage capacity	40 GB
Sound pressure level (printing)	22 dB
Display	-
Market positioning	Business
Envelopes sizes	C5, DL
Maximum print size	297 x 420 mm
Media weight (tray 1)	60 to 105 g/sm2
Paper tray media types	Bond paper, Plain paper, Pre-Printed, Recycled paper
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A3, A4, A5
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	60 - 215 g/m²
Supported network protocols (IPv4)	TCP/IP, IPv6HTTP/HTTPS, LPR/LPD
Standard interfaces	USB 2.0
Power consumption (standby)	95 W
Power consumption (average operating)	615 W
Sustainability certificates	ENERGY STAR
Maximum duty cycle	100000 pages per month
Recommended duty cycle	12000 pages per month
Operating temperature (T-T)	10 - 28 °C
Operating relative humidity (H-H)	15 - 85 %
