Xerox WorkCentre 5890 User Manual

August 2015
5-31
Xerox® WorkCentre® 5890 Family
PL 11.20
Parts Lists
PL 11.20 2K LCSS Staple Head Unit/
T
raverse Assembly
Item Part Description
1
014K11461 Stapler traverse assembly (REP
11.8-110)
2 – Head traverse unit (P/O PL 11.20
Item 1)
3 130E10360 SU1 Home sensor (Q11-370), SU1
Front index sensor (Q11-371)
4 130E10380 SH1 Paper sensor (Q11-361)
5 029K04521 Staple head unit (REP 11.9-110)
6 – Stapler cover (P/O PL 11.20 Item 1)
7 – Staple cartridge (REF: PL 26.10
Item 11)
8 – Not used
9 – Sensor cover (P/O PL 11.20 Item 1)
10 – Staple head assembly (P/O PL
11.20 Item 1)
