Xerox WorkCentre 5890 User Manual

August 2015
5-40
Xerox® WorkCentre® 5890 Family
PL 11.58
Parts Lists
PL 11.58 LVF BM Bin 1 Control
C
omponents (1 of 2)
Item Part Description
1
023E24320 Bin 1 drive belt (REP 11.5-150)
2 – Rear belt clamp (Not Spared) (ADJ
11.1-110)
3 110E20180 Bin 1 upper limit switch (S11-334)
4 – Sensor bracket (Not Spared)
5 130E10360 Bin 1 90% full sensor (Q11-331)
6 – Pulley (Not Spared) (ADJ 40.1)
7 127K55891 Bin 1 elevator motor (MOT11-030)
8 – Front belt clamp (Not Spared) (ADJ
11.1-110)
9 130E20380 Bin 1 motor encoder sensor (Q11-
336)
10 – Stacker tray drive assembly (Not
Spared)
11 007K20531 Stacker tray drive and motor
assembly (REP 11.5-150)
