Xerox WorkCentre 5890

August 2015
5-59
Xerox® WorkCentre® 5890 Family
PL 11.102
Parts Lists
PL 11.102 1K LCSS Docking Latch
Item Part Description
1
– Sensor cover (P/O PL 11.102 Item
8)
2 110K13980 Docking interlock switch (S11-300)
(REP 11.14-120)
3 003K20401 Link bracket assembly (REP 11.14-
120)
4 – Not used
5 – Docking latch (P/O PL 11.102 Item
8) (REP 11.14-120)
6 – Spring (P/O PL 11.102 Item 8)
7 120K02591 Docking actuator
8 003K20391 Docking latch assembly (REP
11.14-120)
