Xerox WorkCentre 5890 User Manual

August 2015
5-45
Xerox® WorkCentre® 5890 Family
PL 11.68
Parts Lists
PL 11.68 LVF BM Staple Head Unit/
T
raverse Assembly
Item Part Description
1
– Stapler traverse assembly kit (REF:
PL 31.12 Item 9) (REP 11.8-150)
2 – Head traverse unit (P/O PL 11.68
Item 1)
3 130E10360 SU1 Home sensor (Q11-370), SU1
Front index sensor (Q11-371) (REP
11.8-150)
4 130E10380 SH1 Paper sensor (Q11-361) (REP
11.8-150)
5 029K04521 Staple head unit (REP 11.9-150)
6 – Stapler cover (P/O PL 11.68 Item 1)
7 – Staple cartridge (REF: PL 26.10
Item 11)
8 – Not used
9 – Sensor cover (P/O PL 11.68 Item 1)
10 – Staple head assembly (P/O PL
11.68 Item 1)
