Xerox WorkCentre 5890 User Manual

August 2015
5-55
Xerox® WorkCentre® 5890 Family
PL 11.86
Parts Lists
PL 11.86 LVF BM Crease Roll
A
ssembly (2 of 3)
Item Part Description
1
– Crease roll gear 1 (P/O item 13)
(REP 11.26-150)
2 – Crease roll gear 2 (P/O item 13)
(REP 11.26-150)
3 – Crease roll gear 3 (P/O item 13)
(REP 11.26-150)
4 – Crease roll gear 4 (P/O item 13)
(REP 11.26-150)
5 127E17650 Crease roll motor (MOT11-062)
(REP 11.25-150)
6 – Spacer (Not Spared)
7 130E10360 Crease roll motor encoder sensor
(Q11-419) (REP 11.25-150)
8 – Crease roll gearbox assembly (P/O
PL 11.86 Item 10)
9 031E16720 Rear crease roll lever (REP 11.24-
150)
10 007K20520 Crease roll motor and gearbox
assembly (REP 11.25-150)
11 013E43940 Crease roll bearing (REP 11.24-
150)
12 899E07760 Crease roll spring (x2) (REP 11.24-
150)
13 807E46770 Crease roll gear kit (REP 11.26-
150)
